Daikin VAM150GJVE 41.7L/s ERV


Price On Application

Daikin's HRV (Heat Reclaim Ventilation) recovers thermal energy lost through ventilation and holds down room temperature changes caused by ventilation, thereby maintaining a comfortable and clean environment. This also curbs the load on the air conditioning system and conserves energy.


Efficient ventilation is a key element of building regulations. Daikin’s heat recovery ventilation modules can be applied as standalone units or incorporated within the air conditioning system. Temperature and humidity are exchanged between the supply and exhaust air, recovering potential energy losses and reducing the air conditioning loads. The HRV modules feature a high efficiency VAM heat exchanger which enables the exchange of both sensible and latent heat energy and substantially increasing the energy transfer capacity.


The Daikin VAM150GJVE has an airflow of 41.7L/s (150m3/h) with a temperature exchange efficiency rating from 79% - 85%.


Power Supply Ø, V, Hz 1, 220 - 240 / 220, 50 / 60
Temp. Exchange Efficience (%) [50Hz/60Hz] Ultra-High 79
High 79
Low 84
Enthalpy Exchange Efficiency (%) [50Hz/60Hz] For Heating Ultra-High 72
High 72
Low 76
For Cooling Ultra-High 66
High 66
Low 70
Sound Level dB(A) [50Hz/60Hz] Heat Exchange Mode Ultra-High 27 - 28.5
High 26 - 27.5
Low 20.5 - 21.5
Bypass Mode Ultra-High 28.5 - 29.5
High 27.5 - 28.5
Low 22.5 - 23.5
Casing   Galvanized Steel Plate
Insulation Material   Self-extinguishable Polyurethane Foam
Dimensions (HxWxD) mm 278 x 810 x 551
Weight kg 24
Heat Exchange System   Air to air cross tow total heat exchange
Heat Exchange Element Material   Specially processed nonflammable paper
Air Filter   Multidirectional Fibrous Fleeces
Fan Type   Sirroco Fan
Air Flow Rate (L/h) [50 Hz/60 Hz] Ultra-High 150
High 150
Low 100
External Static Pressure (Pa) [50Hz/60Hz] Ultra-High 120
Brand Daikin
Shipping Weight 24.0000kg
Shipping Width 0.810m
Shipping Height 0.278m
Shipping Length 0.551m

Daikin offers a 5-year warranty for all of their Air conditioners and controllers.
