Bonaire CRC6911150-SET 5.2kW Wi-Fi Wall Split Air Conditioning System

Bonaire 5.2kW CRC6911150-SET Series 3 Hi-Wall Split Air Conditioner (Built In Wi-Fi) - Includes Outdoor Unit and Controller

The Bonaire Series 3 High Efficiency Split System offers superior comfort with eco-friendly R32 refrigerant and WiFi control. Featuring a Gold Fin coated indoor coil for durability, it comes with a industry leading 7-year warranty. The system is DRED enabled, enhancing energy efficiency and reducing costs. Enjoy a sustainable and reliable climate solution for your home or office with this advanced air conditioning system.

Designed with cutting-edge technology and environmental consciousness, this air conditioning system is perfect for creating the ideal indoor climate in any season.

Key Features:

Wifi Included: Stay connected and in control with integrated WiFi functionality. Adjust settings, set schedules, and monitor your system from anywhere using your smartphone or tablet.
Environmentally Friendly R32 Refrigerant: Utilizes the eco-friendly R32 refrigerant, which has a lower global warming potential compared to traditional refrigerants, reducing your environmental footprint.
7 Year Warranty: Enjoy peace of mind with a industry leading 7-year warranty, ensuring long-term reliability and performance.
Gold Fin Coating: The Gold Fin coating provides superior resistance to corrosion, enhancing durability and maintaining optimal performance over time.
DRED Enabled: Demand Response Enabling Device (DRED) capability allows your system to be more energy-efficient and responsive to grid demands, helping you save on energy costs.

Upgrade to the Bonaire Series 3 High Efficiency Split System and enjoy the perfect balance of comfort, efficiency, and sustainability in your home or office.

(CRC6911150-SET)

System Name	CRC6911125-SET	CRC6911135-SET	CRC6911150-SET	CRC6911171-SET	CRC6911182-SET
Indoor Unit	CRC6911125	CRC6911135	CRC6911150	CRC6911171	CRC6911182
Outdoor Unit	CRC6911025	CRC6911035	CRC6911050	CRC6911071	CRC6911082
Power Supply	1 Phase, 220 ~ 240V, 50Hz
Cooling Capacity Rated/Min-Max (kW)	2.6 (1.0-4.0)	3.5 (1.0-4.0)	5.2 (1.2-6.0)	7.2 (2.0-8.0)	8.2 (2.0-8.4)
Heating Capacity Rated/Min-Max (kW)	4.0 (1.0-4.8)	4.5 (1.0-4.6)	5.2 (1.2-6.0)	7.2 (2.0-8.5)	8.2 (2.2-8.8)
Max Current Cool/Heat (A)	6.6 / 7.4	7.8 / 8.2	12.0 / 11.5		14.0 / 15.0
Star Rating (H/Avg/C) - Cool	9.5 / 5.5 / 6.0	5.5 / 4.5 / 4.5	4.0 / 3.5 / 3.5	3.5 / 3.5 / 3.5	3.5 / 3.0 / 3.5
Star Rating (H/Avg/C) - Heat	3.5 / 2.5 / 2.0	3.0 / 2.5 / 2.0			3.5 / 2.5 / 2.0
Annualised Energy Efficiency Ratio	4.338	4.30	3.669	3.76	3.54
Annualised Coefficient of Performance	4.056	4.15	4.273	4.19	3.665
Sound Power Level dBA - Indoor	26 - 48	32 - 48	31 - 50	36 - 54	40 - 52
Sound Power Level dBA - Outdoor	58	60	63	64	65
Indoor Dimensions (HxWxD) (mm)	195 x 820 x 306		222 x 1097 x 332
Outdoor Dimensions (HxWxD) (mm)	540 x 795 x 305		600 x 853 x 349	699 x 920 x 380	800 x 967 x 421
Indoor Weight Net/Gross (kg)	10/12		13.5/16.5	14/17
Outdoor Weight Net/Gross (kg)	22/24	26/28	34/38	42/45	47/51
Breaker Size (A)	16			20
Pipe Sizes (mm) (Liquid/Gas)	6.35 / 9.52		6.35 / 12.7
Installation - PreCharge (m)	5
Installation - Max Distance L/H (m)	15 / 5
Installation - Additional Charge (g/m)	15		25
Set Temp Range (C)	16 to 30
R32 Refrigerant (kg)	0.62	0.81	0.96	1.12	1.27
